I thought I'd share my sff rig from around 2013. I used it for about a year until I repurposed the parts into other builds. The only tools I had for this were a screw driver, zip ties and scissors so there was no modification involved.

Athlon X4 750K, XFX 7970, 16GB VLP (very low profile) DDR3, 240GB SSD, XFX 550w all inside of a Fractal Design Node 304. I really wanted this Phanteks hsf, but the AMD mounting holes would have the fans sideways. So I used an Enzotech socket adapter that mounted to the AMD motherboard and offered up Intel 115X pegs. It worked well enough for the X4 processor.

It was a fun a build but I moved on from it because Fractal Design's scandinavian design philosophy just didn't resonate with me. The case quality, finish was impeccable. But it was so understated that it felt suffocating. These days that's changing, I absolutely love their new Torrent.


Attachments

  • sff_rig-01.jpg
    272.3 KB · Views: 67
  • sff_rig-02.jpg
    261.2 KB · Views: 60
  • sff_rig-03.jpg
    293.4 KB · Views: 54
  • sff_rig-04.jpg
    254.3 KB · Views: 51
  • sff_rig-05.jpg
    272.6 KB · Views: 48
  • sff_rig-06.jpg
    330.4 KB · Views: 45
  • sff_rig-07.jpg
    237.6 KB · Views: 44
  • sff_rig-08.jpg
    187.8 KB · Views: 43
  • sff_rig-09.jpg
    255 KB · Views: 39
  • sff_rig-10.jpg
    246.1 KB · Views: 38
  • sff_rig-11.jpg
    321.8 KB · Views: 38
  • sff_rig-12.jpg
    302.5 KB · Views: 42
  • sff_rig-13.jpg
    347.6 KB · Views: 53

rsaeon

Disciple
The Athlon X4 SFF rig above was upgraded to an FX 9590 in an NZXT S340. I still remember how impressed I was with this case, it also marked my return to PC modding since the LGA775 days. I modded the power supply here with custom length cables for clean cable management. The 7970 was replaced by XFX with a 280x after an RMA.

This build won 'Job of the Month' over at r/cablemanagement a few years ago and was mentioned in a blog post or two.


Attachments

  • nzxt_S340-21.jpg
    150.3 KB · Views: 34
  • nzxt_S340-20.jpg
    149 KB · Views: 34
  • nzxt_S340-19.jpg
    182.1 KB · Views: 33
  • nzxt_S340-18.jpg
    130.6 KB · Views: 31
  • nzxt_S340-17.jpg
    155 KB · Views: 31
  • nzxt_S340-16.jpg
    143.3 KB · Views: 33
  • nzxt_S340-15.jpg
    114.8 KB · Views: 32
  • nzxt_S340-14.jpg
    157.2 KB · Views: 33
  • nzxt_S340-13.jpg
    136.8 KB · Views: 31
  • nzxt_S340-12.jpg
    120.7 KB · Views: 34
  • nzxt_S340-11.jpg
    184.4 KB · Views: 34
  • nzxt_S340-10.jpg
    210.9 KB · Views: 33
  • nzxt_S340-09.jpg
    177.9 KB · Views: 29
  • nzxt_S340-08.jpg
    162.7 KB · Views: 31
  • nzxt_S340-07.jpg
    131.4 KB · Views: 29
  • nzxt_S340-06.jpg
    173.3 KB · Views: 24
  • nzxt_S340-05.jpg
    218.1 KB · Views: 24
  • nzxt_S340-04.jpg
    203 KB · Views: 25
  • nzxt_S340-03.jpg
    189.5 KB · Views: 22
  • nzxt_S340-02.jpg
    134.8 KB · Views: 24
  • nzxt_S340-01.jpg
    220.3 KB · Views: 40

roofrider

I got one of these too! o_O
Adept
How do you make these custom cables? Even the rig you posted in the show off thread had it and it looks super clean.


rsaeon

Disciple
I reuse the original connectors, it took a while to figure out how to remove the existing wires using micro screwdrivers. I was able to source the pins at an electronics component store locally, both the motherboard/cpu/pcie and molex. The sata connectors and pins I purchased from performance-pcs over a decade ago. For the actual wire, I purchased a 100m bundle of 1 sq mm wire from an electrical shop. They do have some really nice colour sometimes, there's a candy pink that I want to try using sometime. The biggest investment was a crimping tool, it was around 2k: https://www.google.com/search?q=sn-01b&source=lnms&tbm=shop

It takes around four to six hours to completely redo a power supply, but I haven't done one in years because we now have budget power supplies with all black cables. I really like Silverstone's VIVA's cables.

Here's a 2002 dell power supply I did a few years ago for an Athlon XP system. I sometimes use molex pins at the power supply (as you can see here) so that I can swap power supplies at a later date.


Attachments

  • firewall_v7+pc-41.jpg
    207.1 KB · Views: 27
  • firewall_v7+pc-42.jpg
    181.9 KB · Views: 25
  • firewall_v7+pc-43.jpg
    254.9 KB · Views: 27
  • firewall_v7+pc-44.jpg
    329.8 KB · Views: 31

Slayer88

Disciple
For the actual wire, I purchased a 100m bundle of 1 sq mm wire from an electrical shop. They do have some really nice colour sometimes, there's a candy pink that I want to try using sometime.
I was looking for all black cables but no 1 seems to have them. Do you have a brand name you can share please?


rsaeon

Disciple
These are just regular almost generic finolex wires. I've been trying to source all black ribbon cables but the best option I've seen is an old 80pin ide cable.
