Power bank circuit of mi power bank is designed that way !
Tablet Battery what is White, Red, Black cable, can we connect charge cable direct to motherboard
- Thread starter Skyh3ck
- Start date
Skyh3ck
Forerunner
Ok so I removed the battery and connected the LM2596 module buck converter to the motherboard..
I get 3.7v to the module and motherboard.. but tablet is not starting up.. the red LED is blinking in tab.. which means Tablet is indicating a low battery level...
Is there any way I can fool tablet to think battery is connected..
I get 3.7v to the module and motherboard.. but tablet is not starting up.. the red LED is blinking in tab.. which means Tablet is indicating a low battery level...
Is there any way I can fool tablet to think battery is connected..
Skyh3ck
Forerunner
Windows 10 unbranded ub15ms10 ..
Zowee Technology UB15MS10 Tablet PC User Manual
User manual instruction guide for Tablet PC UB15MS10 SHENZHEN ZOWEE TECHNOLOGY CO.,LTD.
Is there any way.. i can fool the motherboard thinking that battery is attached.. like some people use capacitor
Skyh3ck
Forerunner
so i removed the circuit from battery and it looks like a ling thin circuit, i connected the circuit to the board again without battery and connected the power cable to + and and -
but again nothing works, i checked with the multimeter that circuit is getting 3.7 volt but from there to motherboard, no power.
why
circuit is working fine, then i connected the power cable directly to the motherboard without the circuit, it is getting 3.7 and i increased it to 4.3 volt but still no power
i will try with new usb cable, again
ok, so removed the circuit from the battery and it look like this one
i tried several other ways, like connecting the charger output directly to the motherboard, positive and negative, but no sucess
then i tried a 10k resistor and 10k thermistor and connected negative and white , ..
see
here i connected 10k resistor
i tried with 10k thermistor
then i connected the circuit back to its original connection but wihout the battery and sent power from charge to positive and negative on circuit
i tried the buck converter also,
but its maximum output i could increase to 4.3 volt only becuae it was connected to 5V charger
what else i can try
i think i will change the power cable
using a buck converter with 5V charger is limiting the output to 4.39V max
i am thinking to connect 5V directly from the charger with a new thick cable ?
any suggestion
but again nothing works, i checked with the multimeter that circuit is getting 3.7 volt but from there to motherboard, no power.
why
circuit is working fine, then i connected the power cable directly to the motherboard without the circuit, it is getting 3.7 and i increased it to 4.3 volt but still no power
i will try with new usb cable, again
ok, so removed the circuit from the battery and it look like this one
i tried several other ways, like connecting the charger output directly to the motherboard, positive and negative, but no sucess
then i tried a 10k resistor and 10k thermistor and connected negative and white , ..
see
here i connected 10k resistor
i tried with 10k thermistor
then i connected the circuit back to its original connection but wihout the battery and sent power from charge to positive and negative on circuit
i tried the buck converter also,
but its maximum output i could increase to 4.3 volt only becuae it was connected to 5V charger
what else i can try
i think i will change the power cable
using a buck converter with 5V charger is limiting the output to 4.39V max
i am thinking to connect 5V directly from the charger with a new thick cable ?
any suggestion
Attachments
Last edited:
Manoj Prabhakar
Contributor
so what's the current status of this ?
