Can anyone suggest a free and easy to use tool to modify STL files? I have a simple requirement (see attached) and think I may be able to it myself by modifying an STL on Thingsverse. Any help is appreciated. Cheers.

I can try to help you with any modifications through CAD if you can share the file.



[Slayer88]

I can try to help you with any modifications through CAD if you can share the file.

Thanks so much, man! Basically, id like to keep the holes in the same places just the center part cutout.

Just to clarify, i would like the output like the white frame.

STL is at the link below (couldn't attach as it's too large)

My Customized Fan shroud for 360mm water cooling radiator (parametric) by Bl4ck_B4ron

Customized version of https://www.thingiverse.com/thing:4325366Created with Customizer! https://www.thingiverse.com/apps/customizer/run?thing_id=4325366

www.thingiverse.com

I would like the height of the frame to be 10mm please.

Thank you again!



[Pauljacob]

Thanks so much, man! Basically, id like to keep the holes in the same places just the center part cutout.

Just to clarify, i would like the output like the white frame.

STL is at the link below (couldn't attach as it's too large)

My Customized Fan shroud for 360mm water cooling radiator (parametric) by Bl4ck_B4ron

Customized version of https://www.thingiverse.com/thing:4325366Created with Customizer! https://www.thingiverse.com/apps/customizer/run?thing_id=4325366

www.thingiverse.com

I would like the height of the frame to be 10mm please.

Thank you again!

Done! The file is uploaded to Thingiverse: https://www.thingiverse.com/thing:6666099. Let me know if any changes need to be made...



[Slayer88]

Done! The file is uploaded to Thingiverse: https://www.thingiverse.com/thing:6666099. Let me know if any changes need to be made...

You sir are a legend. Not sure where you are based, but if you are in Mumbai I will buy you a beer (or whatever is your poison) Thanks a ton!!



[Pauljacob]

You sir are a legend. Not sure where you are based, but if you are in Mumbai I will buy you a beer (or whatever is your poison) Thanks a ton!!

Hey, thanks for the offer, but I'm happy to help a fellow member out



[harihar]

I can try to help you with any modifications through CAD if you can share the file.

What software are you using to modify the STL file? I tried blender which does work good with mesh files but is not suitable for CAD related.



[Pauljacob]

What software are you using to modify the STL file? I tried blender which does work good with mesh files but is not suitable for CAD related.

I recreated the model from scratch
in fusion 360 from the 120mm fan specifications. The geometry was pretty simple...
Let me know if you need help with modelling anything...
